6N135-X017T 8-SMD OPTOISO 5.3KV TRANS W/BASE 8SMD

Brand: Vishay Semiconductor Opto Division

Product Code: #1763137

Availability:Out of stock

6N135-X017T Description6N135-X017T Datasheet
Compare Parts
Part Number 6N135-X017T-ND
Number of Channels 1
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 7% @ 16mA
Current Transfer Ratio (Max) -
Turn On / Turn Off Time (Typ) 300ns 300ns
Rise / Fall Time (Typ) -
Input Type DC
Output Type Transistor with Base
Voltage - Output (Max) 15V
Current - Output / Channel 8mA
Voltage - Forward (Vf) (Typ) 1.33V
Current - DC Forward (If) (Max) 25mA
Vce Saturation (Max) -
Operating Temperature -55C ~ 100C
Mounting Type Surface Mount
