ILD610-2X007T 8-SMD OPTOISO 5.3KV 2CH TRANS 8SMD

Brand: Vishay Semiconductor Opto Division

Product Code: #1763480

Availability:Out of stock

ILD610-2X007T DescriptionILD610-2X007T Datasheet
Compare Parts
Part Number ILD610-2X007T-ND
Number of Channels 2
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 63% @ 10mA
Current Transfer Ratio (Max) 125% @ 10mA
Turn On / Turn Off Time (Typ) 3.2s 3.4s
Rise / Fall Time (Typ) 2.5s 2.6s
Input Type DC
Output Type Transistor
Voltage - Output (Max) 70V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.25V
Current - DC Forward (If) (Max) 60mA
Vce Saturation (Max) 400mV
Operating Temperature -55C ~ 100C
Mounting Type Surface Mount
